1. Before starting the stone engraving machine, make sure that all connections between the machine tool and the computer are normal, and then turn on the power of the machine tool and the computer. After the system is started, enter the NCStudio CNC system.
2. After opening the control system, select the menu of “Back to Mechanical Origin”. The machine tool will automatically return to the machine origin, and the system coordinate system will be corrected. In some cases, such as restarting the machine and continuing the last operation after the last normal shutdown, the user does not need to perform the mechanical reset operation. When the NCStudio system exits normally, the current coordinate information will be saved. Alternatively, this action may not be performed if the user confirms that the current location is correct.
3. Before processing, the user generally needs to load the required processing program, otherwise, some functions related to automatic processing are invalid. Select the “Open (F) | Open (O)…” menu, the Windows standard file operation dialog box will pop up, and you can select the drive, path and file name where the file to be opened is located. After clicking the “Open” button, the machining program will be loaded into the system.
4. Determine the origin of the workpiece, manually move the X and Y directions of the stone engraving machine to the desired origin position on the workpiece, and select the “Set the current point as the origin of the workpiece” menu, or set the coordinate value of the current position in the coordinate window. Clear to zero, so that the current position is used as the starting point for processing when the processing program is executed.

Configuration of stone engraving machine:
1. Light stone engraving machine 1224 screw drive, cast iron bed, circular rail 3kw motor, stepper motor 450A. Weihong control system (ie computer control), low price
2. Rack drive, equipped with stone engraving machine and square tube seamless machine tool, round rail 25. is a commonly used one. 3k/4.5kw motor. You can also choose a helical rack, stepper motor 450A or 450B, the latter model is larger.
3. High configuration: heavy-duty stone engraving machine, large square tube seamless welding machine tool, T-shaped bed, steel plate gantry, stepper motor 450B, driver 860, rack drive Taiwan Shangyin square rail. high cost. Prices are high.
4. Stone woodworking engraving machine (with the same configuration as the woodworking engraving machine, a stainless steel sink is added). Rack square rail 3kw/4.5kw spindle motor, stepper motor 450B, driver 860.
To sum up the above, the commonly used stone engraving machines on the market today, rack-driven circular rail 25, 4.5kw motor, and popular machines. It is better to choose the helical rack, with large contact area, high speed and high precision. It is more powerful against hard rocks. fair price. If necessary, please consult the manufacturer for details.
